KA46CXA4001

CX-Series amps reach massive power levels thanks to an optimized circuit layout and the highest-grade internal components. Highly efficient heat sinks keep the amp cool with a sophisticated look. Mono amps offer an optional remote level control to adjust your bass right from the dash.

CX-Series Mono Amps are now one-ohm stable, giving you even more power and wiring options for your system! Using efficient Class-D power, the CXA400.1 features a variable bass boost with KickEQ, giving you as much as a 6dB of extra bump with a simple turn of the optional CXARC Remote Bass Controller. A powerful 12dB crossover and 24dB subsonic filter is included, letting you quickly tune your system to perfection. Use the full-range outputs to expand your system with other bass amps, or a full-range amp to complete your system.

CX Amplifiers accept up to 40 volts (400 watts) of speaker-level input signal. This kind of flexibility both makes line-out converters unnecessary and optimizes your sound quality at the same time!

Expand your system with full-range, RCA pass-through outputs, then choose a "standard" mount or a cool vertical mount with the included hardware.

Features:

• Efficient Class-D amplifier
• Three-second turn-on/off delay to eliminate unwanted interference
• Variable 12dB crossovers provides control to dial in perfect sound
• KickEQ™ 6dB variable bass boost for those additional low frequencies
• 24dB subsonic filter for protection from potentially damaging frequencies
• FIT+™ (Fail-safe Integration Technology-PLUS) means it works with nearly every radio
• Accepts up to 40-volt input signal
• Small footprint for easier installation
• Compatible with CXARC Remote Bass Control
• Vertical mounting hardware included for another unique look

Spec:

RMS Power
- 14.4V 4 Ohm mono = 1% THD+N : 150 W x 1
- 14.4V 2 Ohm mono = 1% THD+N : 300 W x 1
- 14.4V 1 Ohm mono = 1% THD+N : 400 W x 1 +/-10%

- Length - 8 1/8" (20.6 cm)
- Height - 2 3/8" (5.9 cm)
- Width - 6 3/4" (17 cm)
- Frequency Response - 25-200 Hz (+/- 1 dB)
- Signal-to-Noise Ratio - >95dB A-weighted, re: rated power
- Input Sensitivity Low Level - 250mV-10V
- Input Sensitivity High Level - 1V-40V
- Active Crossover - 50-200 Hz, 12dB/octave low pass only
- Subsonic Filter - 25 Hz, 24dB/octave
- KickEQ Boost - variable 0-6dB, centred at 40 Hz
- Remote Bass - CXARC (Sold Seperately)
