Solo X L7X 12" Dual Voice Coil Subwoofer - 1 Ohm
The legend returns!
The 12-inch KICKER's SoloX® L7X™ Ferrite Competition Subwoofer brings the most advanced bass technology and unprecedented performance, from the guys who invented it for a vehicle.
A motor like no other – it includes a massive, triple-stacked ferrite magnet surrounding a hyper-extended pole piece, engineered for an enormous, more linear magnetic field and amazing heat dissipation. It's ultra-deep bass at very high volume.
L7X's three-inch voice coil is supported by a dual-spider suspension system, and the double-pressed pulp cone is attached to an ultra-long-throw Santoprene surround - equipped with KICKER's square cone tech and ribbed corners for continuous force and air movement.
Heat is the enemy of endurance. To make our subs even more reliable, KICKER engineers developed Forced-Air Cooling™ which helps SoloX subwoofers run significantly cooler and last longer.
Wiring has never been easier with KICKER’s unique SoloX terminals. Each spring-loaded terminal accepts up to an 8 AWG wire, plus a dual, 8 AWG terminal block above it, making series or parallel wiring a breeze.
Using an exclusive, surround compression system, bolt-on spider landing, and helpful alignment shims, the L7X pre-assembled cone assembly gets you from blown to bumpin’ in minutes – no gluing required!
- Size 12" (30 cm)
- Rated Impedance - 1 Ohm DVC
- Recommended Amplifier Power (RMS) - 1000-2000 W
- Frequency Response 20-100 Hz
- Xmax - 1.25" (31.25 mm)
- Mounting Cutout - 11-1/16" (28.1 cm)
- Mounting Depth - 10-1/8" (25.7 cm)
- Rec. Vented Box Volume - 3 cubic ft (84.9 L)
- Port Opening - 3.5" x 13" (9 x 33 cm)
- Port Length - 36.5" (93 cm)
- Vented Enclosure Tuning Frequency - 31 Hz
